Model

DGPI-RTV-007 AGV handling robot lithium battery

battery Specification

15S1P/48V/60Ah

nominal Voltage

48V

nominal capacity

60Ah

charging voltage

54.75V

charging current

≤ 30A

discharge current

≤ 60A

discharge overcurrent protection Current

85A(10s), 120A(100ms)

discharge cut-off voltage

41.25V

Cell specifications

guoxuan/square 63Ah/lithium iron phosphate

finished product internal resistance

≤ 30 Mohm

battery weight

26Kg ± 3Kg

product Size

l560mm*W295mm*H120mm(Max)

charging temperature protection

0°C to 55°C

Discharge temperature protection

-20°C ~ 60°C

battery shell

metal Shell

lithium battery protection

short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, equalization, etc.

Communication mode

RS485 & RS232
