Brand Guarantee: optional a Brand Cell

Long Life: battery Cycle Times> 2000

System Security: equipped with Smart BMS to Monitor the Battery Status in Real Time and Protect the Battery

Fast Charge: sustainable 1C Current Charging

Model	DGPI-8S40Ah-011
nominal Voltage	24V
nominal capacity	40Ah
charging current	≤ 40A
discharge current	≤ 60A
Instantaneous discharge current	120A
cell specifications	lithium iron phosphate square cell
finished product internal resistance	≤ 100 Mohm
battery weight	15Kg ± 1Kg
product Size	L250mm * W180mm * H150
communication mode	RS485 & RS232
Lithium battery protection	short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, equalization, etc.
